2000 GALLON CJ SERIES WATER TENDER

Off the beaten path, Our 2000 Gallon tanker can’t be beat

The 2000 Gallon CJ Series Water Tender is a purpose-built tender designed to deliver water where it’s needed most—especially in areas without hydrants. With a shortened wheelbase and modified rear bumper, it’s tailored for departments operating in mountainous terrain, valleys, and regions with steep or narrow access roads. Whether you’re supporting wildland operations or rural structure protection, this tender is engineered for reliable water transport and deployment.

We have stock units available for striping, lettering, and delivery to your station within weeks, nationwide.

Recently Delivered

Trucks shown may contain optional features.

FEATURES

Kenworth T480 chassis
PACCAR PX-9 450 HP engine
Allison 3000 EVS transmission
Hale 1000 GPM PTO pump
2000 gallon poly tank
2000 gallon folding tank
One (1) 10″ Newton swivel dump valve
Full-length hose bed
Two (2) 2-1/2” direct tank fills
AMDOR roll-up doors
Whelen LED NFPA lighting & siren package

Features may vary based on your location and customization needs.

Chassis: Kenworth T480, 2-Door

Engine: Paccar PX-9, 450 HP

Transmission: Allison 3000, 5-Speed

GVW: 40,600 lbs. (Front Axle: 14,600 lbs | Rear Axle: 26,000 lbs.)

Wheels: Alcoa Mirror Polish Aluminum

Battery Conditioner: Kussmaul Chief 6012 series battery conditioner

Auxiliary Air Compressor: Kussmaul 12V auxiliary air compressor

Fuel Tank Capacity: 50 gallons

Air Horns: Two (2) Hadley chrome plated

Center Console: Yes

Tank: 2000 US gallons

Hard Suction: Two (2) 6.00″ X 10′ sections of suction hoses

Body: Aluminum diamond plate

Compartment Door Type: AMDOR roll-up doors, satin finish

Compartment L1 & R1: Approx. 60.00″W x 26.00″D x 27.00″H

Compartment L2 & R2: Approx. 60.00″W x 26.00″D x 27.00″H

Rear Camera Notch: Recessed mounting area for a backup camera

Rear Dump Valve: Swivel and manual extension, Stainless Steel

Direct Tank Fill: Two (2) 2.50″ Akron

Hose Bed Cover: Vinyl

Additional: Custom in-house graphics can be applied to the unit

Pump: Hale, MBP, 750 GPM, Side Kick

Special Features: Pump and Roll

Power Take Off: Ten (10) bolt Chelsea model 870-XDFJP-B5XV

Pump Shift: Pump and Roll – MBP/RSD

Hose Threads: NST hose threads

Master Pump Drain: Class 1 master pump drain

Priming System: Trident model manual AirPrime

Intake Relief Valve: Class 1 stainless-steel intake relief valve

Pressure Governor System: Fire Research Pump Boss Max series PBA501-D00

Water Level Gauge: One (1) Innovative Controls Soft-Glo & three (3) Innovative Controls Soft-Glo Mini Monster

Discharges: Three (3) 2.50″ and Two (2) 1.75″

12 Volt Electrical System: Yes

Cab Ground Lights: Two (2) LED chassis ground lights

Ground Lights: Pump panel, front, and rear

Ground Lights Activation: Activate when the parking brake is applied

Emergency Lights: Whelen M Series Emergency Lights

Scene Lights: Whelen EZ Series Scene Lights

Lightbar: One (1) Whelen model JE2NFPA 56.00″ lightbar

Siren and Control: One (1) Whelen model 295SLSA1

Siren Speaker: One (1) Federal Signal model ES100

• Larger pumps – up to 1500 GPM
• Multiple dump valve configurations
• Side or top mount pump modules
• Deck gun
• Federal Q2B siren
• Hannay electric rewind booster reel
• SCBA bottle holders

Download the Full Specs and Sales Drawing Here:

FULL SPECS (PDF)

SALES DRAWING (PDF)
